3D modeling and renders of Roller (product images)
There are no design documents – this modelling is all by visual inspection and common sense.
- Once the basic model is prepared, 3 hero angles will be agreed upon and photorealistic renders generated for those angle in the original Stainless Steel, plus 3 new colours (see below)
- Current models have a 75mm diameter main aluminium tube – New CAD model however will show a 100mm diameter tube
- Assume square tubing for end frames is 40mm x 40mm
- When uncertain of anything, simply ask (I will reply immediately).
Previous 3D Models
New Colours in Addition to the Existing Stainless Steel
Satin Black
White
Shale Grey (Colourbond)
Colour Values
CMYK : 10 4 11 26
RGB : 189 191 186
HEX #BDBFBA
